4069 Hex Inverter/NOT Gate Dip

CD4069 IC Hex Inverter/NOT Gate

The CD4069 is a hex inverter, meaning it contains six individual inverters/NOT-gates. The chip has 14 pins and is commonly used for pulse-shaping, high-input impedance amplifiers, or logic circuits, such as oscillators, flip-flops, and counters.

Pinout:

Pin Overview

Pin overview for the 4069 IC

What is an Inverter/NOT gate?

The CD4069 is a CMOS logic chip that contains six independent inverters. It is used to invert a signal, meaning it takes an input signal and produces an output signal that is the opposite of the input.

How to Use the CD4069 in a Circuit?

To use the CD4069 in a circuit, you need a power supply voltage of 3 to 15V (some versions support up to 20V, so check the datasheet of your version). Connect the power supply to the VDD and GND pins of the chip. You can now use any of the six inverters in the chip.

Technical Specifications

• Case/Package: PDIP
• Contact Plating: Gold
• Mount: Through Hole
• Number of Pins: 14
• High Level Output Current: -4.2 mA
• Logic Function: Inverter
• Low Level Output Current: 4.2 mA
• Max Operating Temperature: 125 °C
• Max Output Current: 6.8 mA
• Max Supply Voltage: 18 V
• Min Operating Temperature: -55 °C
• Min Supply Voltage: 3 V
• Number of Bits: 6
• Number of Channels: 6
• Number of Circuits: 6
• Number of Elements: 6
• Number of Gates: 6
• Number of Inputs: 1
• Output Current: 6.8 mA
• Propagation Delay: 110 ns
• Quiescent Current: 5 µA
• Schmitt Trigger Input: No
• Termination: Through Hole
• Turn-On Delay Time: 110 ns

Datasheet

Handling & Safety

Always confirm the rating, polarity and pinout of a logic ic before installing it, and avoid exceeding its rated voltage or current. Use proper ESD precautions with sensitive parts. These steps protect your circuit and keep your work safe.

Why Choose This Logic IC

First, it is a widely used part in electronics repair, prototyping and assembly, so it fits into most existing projects easily. Second, the value, rating or pin count is clearly stated, so you can match it to your circuit with confidence. Third, our team checks basic function before it ships. So, you avoid guesswork when you order. As a result, this is a dependable choice for repair, prototyping or a finished project.

Usage Tips

Before soldering or installing, match the value, package and pin layout with your circuit diagram. Therefore, you avoid a wrong fit or a damaged board. Also, keep small parts stored in labeled bags so values do not get mixed up during a project. As a result, your build stays organized and easier to troubleshoot.

Good to Know

A well-matched logic ic saves time on the job later. Therefore, double-check the value, rating and pin layout against your circuit before relying on it in a final build. Also, keep the original packaging until you have tested the part, since this makes any exchange easier if something is not right. As a result, your project stays reliable with fewer surprises.

4069 Hex Inverter/NOT Gate Dip

4069 Hex Inverter/NOT Gate Dip دائرة منطقية مخصص لـ تنفيذ وظيفة منطقية رقمية داخل الدائرة.

الاستخدامات

• تصميم الدوائر الرقمية
• منطق مساعد للميكروكنترولر
• إصلاح البوردات الرقمية ودوائر التحكم
• مشاريع الإلكترونيات المنزلية

ملاحظات الأمان

تأكد دايمًا من القيمة والقطبية وترتيب الأرجل بتاعة دائرة منطقية قبل التركيب، وماتتخطاش الجهد أو التيار المسموح بيه. استخدم احتياطات الشحنة الساكنة (ESD) مع القطع الحساسة. الخطوات دي بتحمي دائرتك وتخلي شغلك آمن.

ليه تختار دائرة منطقية ده

أولاً، قطعة مستخدمة بشكل واسع في إصلاح وتجميع الدوائر الإلكترونية، فتتناسب مع معظم المشاريع بسهولة. ثانيًا، القيمة أو التصنيف أو عدد الأرجل موضحة بدقة، فتقدر تطابقها مع دائرتك بثقة. ثالثًا، بنتأكد من الوظيفة الأساسية قبل الشحن. فهو اختيار موثوق للإصلاح أو التجربة أو مشروع متكامل.

تقدر تستعرض باقي المكونات الإلكترونية عندنا لمشروعك القادم.
