NE555 Timer Module
49,50 EGP
Out of stock
NE555 Timer Module
The NE555 Timer Module is one of the most widely used integrated circuits in electronics, known for its exceptional reliability and versatility in timing, delay, and pulse generation applications. This module simplifies circuit design for engineers, students, and hobbyists who require precise control over time-based operations.
Key Features:
-
Utilizes the popular NE555 Timer IC, capable of operating in astable and monostable modes.
-
Adjustable frequency and duty cycle through external resistors and capacitors.
-
Supports both continuous and single pulse output configurations.
-
Wide supply voltage range, typically from 4.5 V to 15 V DC.
-
Provides stable operation with low power consumption and minimal drift over temperature variations.
-
Compact PCB design, ideal for integration into various electronic projects.
-
On-board components include resistors, capacitors, and connectors for quick setup.
-
LED indicator for output status monitoring.
Applications:
-
Pulse Width Modulation (PWM) generation.
-
LED and lamp flashers.
-
Frequency generators and oscillators.
-
Time delay circuits (delay-on or delay-off).
-
Tone generation and sound effects in audio systems.
-
Square wave generation for digital logic testing.
-
Servo motor control and robotics projects.
Advantages:
-
Simple to use and configure.
-
Highly stable timing performance.
-
Low-cost yet powerful timing solution.
-
Compatible with breadboards and development kits such as Arduino and Raspberry Pi.
-
Suitable for both educational experiments and industrial control systems.
Technical Specifications (Data Sheet Summary):
| Parameter | Value |
|---|---|
| Operating Voltage | 4.5 V – 15 V DC |
| Operating Modes | Astable / Monostable |
| Output Current | Up to 200 mA |
| Frequency Range | Up to 100 kHz (adjustable) |
| Duty Cycle | Adjustable (via potentiometer or resistors) |
| Operating Temperature | 0 °C – 70 °C |
| Output Type | Digital (High/Low) |
| Dimensions | Approx. 32 × 22 mm |
The NE555 Timer Module remains a cornerstone in electronic circuit design because of its adaptability, low price, and robust performance. Whether you’re designing automatic lights, signal generators, or timing controllers, this module delivers consistent and accurate results. It is an essential component for every electronics enthusiast and professional engineer seeking precision and simplicity in one compact package.
