L298 Big Module Red Board (Dual H-Bridge Motor Driver Using L298N)

The double H-Bridge driver module uses ST L298N dual full-bridge driver, an integrated monolithic circuit in a 15-lead Multiwatt and PowerSO20 packages. It is a high voltage, high current dual full-bridge driver designed to accept standard TTL logic levels and drive inductive loads such as relays, solenoids, DC, and stepping motors. Two enable inputs are provided to enable or disable the device independently of the input signals. The emitters of the lower transistors of each bridge are connected together and the corresponding external terminal can be used for the connection of an external sensing resistor. An additional supply input is provided so that the logic works at a lower voltage. Specification Driver: L298N Driver power supply: +5V~+46V Driver Io: 2A Logic power output Vss: +5~+7V (internal supply +5V) Logic current: 0~36mA Controlling level: Low -0.3V~1.5V, high: 2.3V~Vss Enable signal level: Low -0.3V~1.5V, high: 2.3V~Vss Max power: 25W (Temperature 75°C) Working temperature: -25C°~+130°C Dimension: 60mm x 54mm Driver weight: ~ 48g Other extensions: current probe, controlling direction indicator, pull-up resistor switch, logic part power supply.
