13009 Transistor NPN 400V-12A

13009 Transistor NPN 400V 12A

The 13009 Transistor NPN 400V 12A is a high-voltage power transistor designed for switching and amplification in electronic circuits. It delivers strong performance in power supply and high-voltage applications. Therefore, technicians and engineers rely on it for stable and efficient circuit operation.

The 13009 Transistor NPN 400V 12A supports high voltage up to 400V and current up to 12A. As a result, it handles demanding applications such as SMPS power supplies and inverter circuits. In addition, it provides fast switching capability, which improves efficiency in electronic systems.

This transistor features a robust design suitable for high-power environments. Moreover, it ensures stable operation under load conditions, which makes it ideal for industrial and repair applications.

High Power Switching Transistor

Users use in many electronic circuits. For example, it is widely used in switching power supplies, inverters, and driver circuits. In this way, users can control high-power loads efficiently.

The TO-220 package helps with heat dissipation. Furthermore, it allows easy mounting on heatsinks, which improves thermal performance during operation.

Main Features

• NPN power transistor
• High voltage rating up to 400V
• High current capacity up to 12A
• Fast switching performance
• Suitable for SMPS and inverter circuits
• TO-220 package for heat dissipation
• Reliable and durable design

Technical Specifications (Data Sheet)

• Transistor Type: NPN
• Collector-Emitter Voltage (Vce): 400V
• Collector Current (Ic): 12A
• Power Dissipation: Up to 75W (with proper cooling)
• Gain (hFE): 8 – 40 (typical)
• Package: TO-220
• Operating Temperature: -55°C to +150°C
• Application Type: Switching / Amplification

Applications

Users rely on this transistor in many applications. For instance, it is commonly used in:

• Switching power supplies (SMPS)
• Inverter circuits
• TV and monitor power boards
• High-power driver circuits
• Industrial electronics
