Transistor A1370 PNP 100mA 200V

The Transistor A1370 is a precision-designed PNP transistor built for high-voltage and low-current applications that demand superior reliability, fast response, and consistent performance. With a collector current rating of 100mA and a collector-emitter voltage of 200V, the Transistor A1370 is ideal for signal amplification, switching, and voltage control in both industrial and communication systems. It provides high voltage tolerance, low noise output, and stable gain—making it an excellent choice for engineers, audio designers, and electronics enthusiasts seeking dependable and accurate circuit performance.

Key Features

• Type: PNP Silicon High-Voltage Transistor

• Collector Current (Ic): 100mA continuous

• Collector-Emitter Voltage (Vce): 200V

• Collector-Base Voltage (Vcb): 200V

• Emitter-Base Voltage (Veb): 5V

• DC Current Gain (hFE): 40 – 320 (depending on current and voltage)

• Transition Frequency (fT): 100 MHz typical

• Package Type: TO-92 for compact design and efficient performance

Advantages

• High voltage rating (up to 200V) suitable for precision and industrial circuits.

• Low leakage current ensuring reliable signal amplification and switching.

• Excellent frequency response (up to 100 MHz) ideal for high-speed applications.

• Low noise operation, providing clean and stable signal amplification.

• Strong thermal stability and durable silicon construction for long lifespan.

• Compact TO-92 package allows easy installation and PCB integration.

Applications

• Audio Amplifiers: Delivers smooth and distortion-free sound performance.

• Signal Amplifiers: Used for accurate voltage and current signal amplification.

• Switching Circuits: Suitable for low-current, high-voltage control systems.

• Oscillator and Timing Circuits: Provides frequency stability and reliable waveform generation.

• Industrial Electronics: Ideal for control and feedback systems in automation.

Electrical Characteristics (Typical Values at 25°C)

Datasheet Summary

• Model: A1370

• Polarity: PNP

• Collector-Emitter Voltage (Vce): 200V

• Collector Current (Ic): 100mA

• Power Dissipation: 800 mW

• Frequency Response: 100 MHz

• Package Type: TO-92

• Complementary Transistor: C3467 (NPN Transistor)

• Operating Temperature Range: -55°C to +150°C

Conclusion

The Transistor A1370 is a high-voltage, low-current PNP transistor engineered for superior performance and precision. It combines fast switching, low noise, and strong gain stability, making it an excellent component for audio, signal, and control applications. Its compact TO-92 package provides ease of use and thermal reliability, ensuring long-term operation. Whether used in amplifiers, oscillators, or voltage control systems, the Transistor A1370 PNP 100mA 200V guarantees excellent efficiency, accuracy, and durability for both industrial and educational electronics projects.
