2N2641 Dual NPN Transistor

The 2N2641 Dual NPN Transistor is a sophisticated semiconductor solution designed for high-performance differential amplification. This specialized component features two silicon NPN chips within a single package to ensure perfectly matched electrical characteristics. Consequently, it is the preferred choice for engineers working on precision analog instrumentation and low-level signal processing.

Advanced Features of 2N2641 Dual NPN Transistor

Furthermore, this device offers exceptional thermal tracking. Because both transistors share the same substrate in a TO-78 metal can, they experience identical temperature fluctuations. Specifically, this prevents the common “drift” issues found in discrete transistor setups. Additionally, the high DC current gain ($h_{FE}$) remains stable across a wide range of operating conditions.

Optimal Performance in Differential Circuits

The 2N2641 Dual NPN Transistor excels in reducing noise and distortion. Moreover, its low capacitance makes it ideal for high-frequency applications. Specifically, designers use it in the input stages of operational amplifiers to maintain high common-mode rejection ratios. Consequently, your circuits will achieve higher accuracy and cleaner signal output.

Reliable Build and Technical Integration

Furthermore, the rugged metal-can packaging provides excellent shielding against electromagnetic interference. Additionally, the 6-pin configuration allows for straightforward PCB integration. Whether you are repairing vintage audio equipment or developing new laboratory-grade sensors, this component delivers the reliability you need. Specifically, the 2N2641 maintains high voltage ratings and consistent collector currents for demanding industrial environments.

Verified Data Sheet

• Feature: Specification
• Type: Dual NPN Silicon Transistor
• Package: TO-78 (6-Lead Metal)
• Collector-Emitter Voltage ($V_{CEO}$): 45V
• Collector-Base Voltage ($V_{CBO}$): 45V
• Continuous Collector Current ($I_C$): 30mA
• Power Dissipation ($P_D$): 500mW per side
• Operating Temperature: -65°C to +200°C
