IDC Socket Connector Header 16 pin Female

The IDC Socket Connector Header 16 pin Female is a high-quality and precision-engineered connector designed for secure, efficient, and reliable data or signal transmission in electronic systems. It is commonly used in ribbon cable assemblies, industrial equipment, and embedded systems, providing a strong and stable connection between devices.

Key Features:

• High Durability:  is built using premium-grade materials that ensure long-lasting performance and resistance to wear and tear. The plastic housing is heat-resistant and designed to maintain stability even in high-temperature environments.

• Perfect Compatibility: Specifically designed to work with 16-pin male headers and flat ribbon cables, this connector supports a wide range of applications such as control boards, sensors, and digital communication interfaces.

• Ease of Installation: It features a user-friendly design that allows quick assembly without soldering. Simply press the ribbon cable into the connector using an IDC crimping tool, ensuring a precise and reliable contact.

• Secure Locking Mechanism: The latch and guide features ensure proper alignment, preventing accidental disconnections and signal loss during operation.

• Compact Design: With its lightweight and space-efficient structure, it fits seamlessly into dense electronic assemblies and tight spaces.

Technical Specifications (Data Sheet):

• Connector Type: Female IDC Socket

• Number of Pins: 16

• Contact Material: Phosphor bronze with tin plating

• Pitch: 2.54 mm

• Operating Voltage: Up to 250V

• Current Rating: 3A per contact

• Operating Temperature: -40°C to +105°C

• Cable Compatibility: 1.27mm pitch flat ribbon cable

• Mounting Type: Cable mount or panel mount

• Locking Type: Friction and latch mechanism

Applications:

• Used in microcontroller development boards and data bus connections

• Ideal for industrial automation, CNC machines, and signal transmission systems

• Commonly found in prototyping boards, control systems, and communication modules

Why Choose This Product:

 offers consistent performance, easy integration, and dependable signal reliability. Whether you are a professional engineer or a hobbyist, this connector simplifies cable management while maintaining superior electrical connectivity.

This versatile component ensures stable connections, reduces interference, and extends the lifespan of your electronic projects. It’s a cost-effective and efficient choice for anyone building or repairing multi-pin ribbon cable systems.

Data Sheet Summary:

• Voltage Rating: 250V

• Current Rating: 3A

• Pin Count: 16

• Pitch: 2.54mm

• Material: Thermoplastic (UL94V-0)

• Operating Temperature: -40°C to +105°C

Reliable, efficient, and built for performance – the IDC Socket Connector Header 16 pin Female is the perfect solution for modern electronic applications.
