IDC Socket Connector Header 24 pin Male

is a high-quality and durable connector designed to provide a secure and reliable connection for flat ribbon cables and electronic boards. This IDC Socket Connector Header 24 pin Male is ideal for use in embedded systems, prototyping, and a wide range of electronic applications that require precise signal transmission and efficient power delivery.

Key Features:

• High Compatibility:
  The IDC Socket Connector Header 24 pin Male is fully compatible with 24-pin ribbon cables, ensuring easy connection and disconnection without the need for soldering. It supports both 2.54mm pitch cables and standard IDC sockets, making it versatile for various development projects.

• Robust Construction:
  Made from durable, high-grade plastic and copper alloy contacts, this connector offers excellent electrical conductivity and long-lasting performance. The gold or tin-plated pins prevent corrosion, ensuring a stable connection over time.

• Ease of Use:
  With its male header pin configuration, the connector can be mounted directly onto PCBs or breadboards. The design supports easy cable alignment, reducing the risk of wiring errors during installation.

• Reliable Electrical Performance:
   ensures a secure and vibration-resistant connection. It minimizes signal loss and interference, maintaining high data integrity in digital and analog circuits.

• Compact and Space-Saving Design:
  This connector has a compact structure that allows integration into space-constrained electronic devices without compromising connectivity performance.

Technical Specifications (Datasheet):

• Connector Type: IDC Socket Header

• Gender: Male

• Number of Pins: 24

• Pitch: 2.54 mm

• Contact Material: Copper Alloy

• Plating: Gold/Tin over Nickel

• Insulator Material: PBT or Nylon 66 (UL94V-0 rated)

• Operating Voltage: 250V AC/DC

• Current Rating: 1A per contact

• Operating Temperature Range: -40°C to +105°C

• Mounting Type: Through-Hole or Straight Pin

Applications:

• Microcontroller and development boards

• Embedded systems and robotics

• Computer interface modules

• Data communication devices

• Industrial control panels

Why Choose This Connector:

 provides unmatched reliability, making it perfect for engineers, hobbyists, and technicians. Its sturdy build and precise pin alignment ensure stable connections, even in high-vibration environments.

Enhance your electronic setup with this professional-grade connector — ensuring efficient, consistent, and secure data and power transfer in every project.

Datasheet Summary:
This connector follows international IEC standards for pin spacing and contact resistance. It meets RoHS compliance, ensuring environmental safety and reliability for long-term use.
