TDA1675
200,00 EGP
دائرة TDA1675 (فيليبس) شريحة خرج انحراف رأسي لأجهزة استقبال تليفزيون ألوان، نفس الوظيفة الأساسية لـTDA1675A الموجودة كمان في الكتالوج. | The TDA1675 (Philips) is a vertical deflection output IC for color television receivers, the same core function as the TDA1675A also in this catalog.
TDA1675 Vertical Deflection IC (Philips, Second Listing)
The TDA1675 (Philips) is a vertical deflection output IC for color television receivers, the same core function as the TDA1675A also in this catalog.
TDA1675 – How It Works
Like the TDA1675A, it generates the sawtooth-shaped vertical scan drive current for the vertical yoke coil, incorporating internal protection against output stage faults, and is a common replacement part when the vertical deflection section of a Philips-designed or compatible TV chassis fails.
Being the same core part as the TDA1675A also in this catalog, treat it as fully interchangeable when sourcing a replacement for vertical deflection repair work.
Key Features
- Vertical deflection drive for CRT TVs
- Internal output stage fault protection
- Philips consumer TV chip family
Typical Applications
- Color CRT television vertical scan circuits
- Philips-chassis TV repair
- Vintage TV restoration
Datasheet Specifications
- Function: Vertical deflection output driver
- Manufacturer: Philips
- Package: DIP with heatsink tab
For more background, see CRT deflection technology: reference. Browse our full range of ICs and microcontrollers.
TDA1675 Vertical Deflection IC (Philips, Second Listing)
دائرة TDA1675 (فيليبس) شريحة خرج انحراف رأسي لأجهزة استقبال تليفزيون ألوان، نفس الوظيفة الأساسية لـTDA1675A الموجودة كمان في الكتالوج.
TDA1675 – إزاي شغالة
زي TDA1675A، بتولد تيار تشغيل مسح رأسي بشكل سن منشار لملف اليوك الرأسي، ومدمج فيها حماية داخلية ضد أعطال مرحلة الخرج، وهي قطعة استبدال شائعة لما قسم الانحراف الرأسي في شاسيه تليفزيون مصمم من فيليبس أو متوافق يتعطل.
بكونها نفس القطعة الأساسية زي TDA1675A الموجودة كمان في الكتالوج، تعامل معاها كقابلة للتبديل بالكامل لما بتوفر بديل لشغل صيانة انحراف رأسي.
المواصفات الأساسية
- تشغيل انحراف رأسي لتليفزيونات CRT
- حماية عطل مرحلة خرج داخلية
- عائلة شريحة تليفزيون استهلاكي فيليبس
الاستخدامات
- دوائر مسح رأسي تليفزيون ألوان CRT
- صيانة تليفزيون شاسيه فيليبس
- ترميم تليفزيون قديم
المواصفات الفنية
- الوظيفة: درايفر خرج انحراف رأسي
- الشركة المصنعة: فيليبس
- التغليف: DIP بلسان تبريد
لمزيد من التفاصيل التقنية راجع تقنية انحراف CRT على ويكيبيديا، وتصفح باقي الدوائر المتكاملة والمتحكمات المتوفرة عندنا.
