74HC4072 High Speed CMOS Dual 4-Input OR Gate IC (744072) DIP-14 Package

The 74HC4072 is a high speed CMOS DUAL 4-INPUT OR GATE fabricated in silicon gate C2 MOS technology. It has the same highspeed performance of LSTTL combined with true CMOS low power consumption. The internal circuit is composed of 3 stages including buffer output, which gives high noise immunity and stable output. All inputs are equipped with protection circuits against static discharge and transient excess voltage.

Features:-74240 SMD LOGIC GATE

• HIGH SPEED

1. tPD = 9 ns (TYP.) AT VCC =5V

• LOW POWER DISSIPATION

1. ICC = 1 µA (MAX.) AT TA = 25 °C

• HIGH NOISE IMMUNITY

1. VNIH = VNIL = 28 % VCC (MIN.)

• OUTPUT DRIVE CAPABILITY

1. 10 LSTTL LOADS

• SYMMETRICAL OUTPUT IMPEDANCE

1. |IOH|=IOL = 4 mA (MIN.)

• BALANCED PROPAGATION DELAYS

1. tPLH = tPHL

• WIDE OPERATING VOLTAGE RANGE

1. VCC (OPR) = 2 V TO 6 V

• PIN AND FUNCTION COMPATIBLE

1. WITH 4072B

Package Includes:-

1 X 74HC4072 IC – (SMD Package) – High Speed CMOS Dual 4-Input OR Gate IC (744072)
