SGS Z8470AB1 / Z80ADART 40-Pin Dip IC Quantity

423,00 EGP

دائرة Z8470AB1 (SGS، مصدر ثانٍ لـZ80A DART من زيلوج) مستقبل/مرسل غير متزامن مزدوج، بتوفر قناتي اتصال تسلسلي كاملتي الاتجاه مستقلتين لنظام مبني على Z80. | The Z8470AB1 (SGS, second-source of the Zilog Z80A DART) is a Dual Asynchronous Receiver/Transmitter, providing two independent full-duplex serial communication channels for a Z80-based system.

متوفر

Description

Z8470AB1 / Z80A DART Dual Asynchronous Receiver/Transmitter (SGS)

The Z8470AB1 (SGS, second-source of the Zilog Z80A DART) is a Dual Asynchronous Receiver/Transmitter, providing two independent full-duplex serial communication channels for a Z80-based system.

Z8470 – How It Works

Each of its two channels independently handles the serialization/deserialization of data, start/stop bit framing, and baud-rate timing needed for standard asynchronous serial communication (like RS-232), making it possible to add two independent serial ports to a Z80 system with a single chip.

Along with the Z80A CTC and Z80 PIO also in this catalog, the DART rounds out the classic trio of Z80 support peripherals that formed the backbone of countless 8-bit computer and terminal designs.

Key Features

  • 2 independent full-duplex serial channels
  • Asynchronous serial communication (RS-232 compatible)
  • Second-source (SGS) of the Zilog Z80A DART

Typical Applications

  • Dual serial port expansion for Z80 systems
  • Terminal and modem interfacing
  • Vintage Z80 computer restoration and repair

Datasheet Specifications

  • Channels: 2 independent full-duplex serial
  • Bus Compatibility: Zilog Z80
  • Package: 40-pin DIP

For more background, see the Zilog Z80 microprocessor family: reference. Browse our full range of ICs and microcontrollers.


Z8470AB1 / Z80A DART Dual Asynchronous Receiver/Transmitter (SGS)

دائرة Z8470AB1 (SGS، مصدر ثانٍ لـZ80A DART من زيلوج) مستقبل/مرسل غير متزامن مزدوج، بتوفر قناتي اتصال تسلسلي كاملتي الاتجاه مستقلتين لنظام مبني على Z80.

Z8470 – إزاي شغالة

كل واحدة من قناتيها بتتعامل بشكل مستقل مع تسلسل/إلغاء تسلسل البيانات وتأطير بت البداية/النهاية وتوقيت معدل الباود المحتاج للاتصال التسلسلي غير المتزامن القياسي (زي RS-232)، وده بيخلي إضافة منفذين تسلسليين مستقلين لنظام Z80 ممكنة بشريحة واحدة.

مع Z80A CTC وZ80 PIO الموجودين كمان في الكتالوج، DART بتكمل الثلاثي الكلاسيكي لأجهزة دعم Z80 الطرفية اللي شكلت العمود الفقري لتصميمات كمبيوتر وتيرمينال 8 بت لا تعد ولا تحصى.

المواصفات الأساسية

  • قناتين تسلسليتين كاملتي الاتجاه مستقلتين
  • اتصال تسلسلي غير متزامن (متوافق RS-232)
  • مصدر ثانٍ (SGS) لـZ80A DART من زيلوج

الاستخدامات

  • توسيع منفذ تسلسلي مزدوج لأنظمة Z80
  • توصيل تيرمينال ومودم
  • ترميم وصيانة كمبيوتر Z80 قديم

المواصفات الفنية

  • القنوات: قناتين تسلسليتين كاملتي الاتجاه مستقلتين
  • توافق الباص: زيلوج Z80
  • التغليف: DIP بـ40 رجل

لمزيد من التفاصيل التقنية راجع عائلة معالج Zilog Z80 على ويكيبيديا، وتصفح باقي الدوائر المتكاملة والمتحكمات المتوفرة عندنا.
